紧定套型号 |
基本尺寸 Dimensions mm |
重量 Wt kg |
组成件 |
d1 |
d |
d2 |
B1 |
B2 |
G |
套 |
锁紧螺母 |
锁紧垫圈 |
H205
H206
H207 |
20
25
30 |
25
30
35 |
38
45
52 |
26
27
29 |
8
8
9 |
M25×1.5
M30×1.5
M35×1.5 |
0.07
0.10
0.13 |
A205
A206
A207 |
KM05
KM06
KM07 |
MB05
MB06
MB07 |
H208
H209
H210 |
35
40
45 |
40
45
50 |
58
65
70 |
31
33
35 |
10
11
12 |
M40×1.5
M45×1.5
M50×1.5 |
0.17
0.23
0.27 |
A208
A209
A210 |
KM08
KM09
KM10 |
MB08
MB09
MB10 |
H211
H212
H213 |
50
55
60 |
55
60
65 |
75
80
85 |
37
38
40 |
12
13
14 |
M55×2
M60×2
M65×2 |
0.31
0.35
0.40 |
A211
A212
A213 |
KM11
KM12
KM13 |
MB11
MB12
MB13 |
H215
H216
H217 |
65
70
75 |
75
80
85 |
98
105
110 |
43
46
50 |
15
17
18 |
M75×2
M80×2
M85×2 |
0.71
0.88
1.0 |
A215
A216
A217 |
KM15
KM16
KM17 |
MB15
MB16
MB17 |
H218
H219
H220 |
80
85
90 |
90
95
100 |
120
125
130 |
52
55
58 |
18
19
20 |
M90×2
M95×2
M100×2 |
1.2
1.35
1.5 |
A218
A219
A220 |
KM18
KM19
KM20 |
MB18
MB19
MB20 |
H221
H222 |
95
100 |
105
110 |
140
145 |
60
63 |
20
21 |
M105×2
M110×2 |
1.7
1.9 |
A221
A222 |
KM21
KM22 |
MB21
MB22 |
|
