型号
Unit No. |
退卸套尺寸Dimentions of Sleeve |
参考Ret. |
退卸套重量
Weight of Sleeve
(kg) |
|
d1
mm |
Thread
MARK(D1)×Pitch |
L
mm |
L1
mm |
b
mm |
a
mm |
螺母型号
Unit No.of Nut |
轴承内径型号
Brg.lnner dia No. |
|
AH 2308
AH 2309
AHX2310
AHX2311
AHX2312
AH 2313
AHX2316
AHX2315
AHX2316
AHX2317
AHX2318
AHX2319
AHX2320
AH 2321
AHX2322
AHX2324
AH 2332
AH 2334
AHX2330
AH 2332
AH 2334
AH 2336
AH 2338
AH 2340
AH 2344
AH 2348
AH 2352
AH 2356 |
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
115
125
135
165
150
160
170
180
190
200
220
240
260 |
M 45×1.5
50×1.5
55×2
M 60×2
65×2
75×2
M 80×1
85×2
90×20
M 95×2
100×2
105×2
M 110×2
115×2
120×2
M 135×2
165×2
155×2
M 165×3
180×3
190×3
M 200×3
TM210×4
220×4
TM240×4
260×4
290×4
TM310×5 |
40
44
50
54
58
61
64
68
71
74
79
85
90
94
98
105
115
125
135
160
166
154
160
170
181
189
205
212 |
43
47
53
57
61
64
68
72
75
78
83
89
94
98
102
109
119
130
160
166
152
160
167
177
189
197
213
220 |
7
7
9
10
11
12
12
12
12
13
16
16
16
16
16
17
19
20
24
24
24
26
26
30
30
30
30
30 |
10
11
15
16
17.5
15
15
15
15
16
17
19
19
19
19
20
22
23
27
27
27
29
32
36
36
36
36
36 |
AN 09
10
11
AN 12
13
15
AN 16
17
18
AN 19
20
21
AN 22
24
25
AN 27
29
31
AN 33
36
38
AN 40
HN 42
44
HN 48
52
58
HN 62 |
08
09
10
11
12
13
16
15
16
17
18
19
20
21
22
24
26
28
30
32
34
36
38
40
44
48
52
56 |
0.128
0.164
0.209
0.253
0.297
0.395
0.466
0.534
0.597
0.670
0.779
0.886
0.998
1.27
1.35
1.60
2.00
2.33
2.82
4.70
5.30
5.90
6.50
7.50
13.4
15.5
20.0
21.5 |
