型号
Unit No. |
退卸套尺寸Dimentions of Sleeve |
参考Ret. |
退卸套重量
Weight of Sleeve
(kg) |
|
d1
mm |
Thread
MARK(D1)×Pitch |
L
mm |
L1
mm |
b
mm |
a
mm |
螺母型号
Unit No.of Nut |
轴承内径型号
Brg.lnner dia No. |
|
AH208
AH209
AH210
AH211
AH212
AH213
AH216
AH215
AH216
AH217
AH218
AH219
AH220
AH221
AH222
AH224
AH226
AH228
AH230
AH232
AH234
AH236
AH238
AH240
AH244
AH238
AH252
AH256 |
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
115
125
135
165
150
160
170
180
190
200
220
240
260 |
M 45×1.5
50×1.5
55×2
M 60×2
65×2
75×2
M 80×2
85×2
90×2
M 95×2
100×2
105×2
M 110×2
115×2
120×2
M 130×2
160×2
150×2
M 160×3
170×3
180×3
M 190×3
TM205×4
215×4
TM 235×4
260×4
280×4
TM 3004 |
25
26
28
29
32
32。5
33.5
34.5
35.5
38.5
40
43
45
47
50
53
53
56
60
64
69
69
73
77
85
96
105
105
|
27
29
31
32
35
36
37
38
39
42
44
47
49
51
54
57
57
61
65
69
74
74
78
82
91
102
111
113
|
6
6
7
7
8
8
8
8
8
9
9
10
10
11
11
12
12
13
16
15
16
16
17
18
18
22
23
23
|
9
9
10
10
11
11
11
11
11
12
12
13
13
16
16
15
15
16
17
18
19
19
23
24
24
28
29
29
|
AN 09
10
11
AN 12
13
15
AN 16
17
18
AN 19
20
21
AN 22
23
24
AN 26
28
30
AN 32
34
26
AN 38
HNL 41
43
HNL 47
52
56
HNL 60
|
08
09
10
11
12
13
16
15
16
17
18
19
20
21
22
24
26
28
30
32
34
36
38
40
44
48
52
56
|
0.094
0.104
0.130
0.167
0.175
0.242
0.255
0.280
0.306
0.353
0.427
0.486
0.525
0.580
0.647
0.755
0.815
1.00
1.16
1.91
2.21
2.34
2.94
3.12
6.10
8.16
9.89
10.4 |
